MobileHub Einrichtung

Support
1

Hallo,

heute habe ich eine Frage zur Einrichtung des MobileHub. Folgende Konstellation liegt vor:

Fritzbox 7490 (Amt)
620
621
622 (Eingerichteter Account für Mobile Hub)

Der MobileHub wurde gemäß dieser Anleitung eingerichtet:
https://wiki.pascom.net/confluence/pages/viewpage.action?pageId=16253126#MobilityClientüberMobileHub-Übersicht

Bezeichnung: mobilehub
Nummer *: +49305XXXX74
Regel anlegen *: ja
Amt *: fritzbox
Ziel *: 622

Entsprechend der Anleitung wurden nun auch folgende Schritte durchgeführt:

  • Installation des MobyDick Clients im iPhone
  • Mobilgerät für Mobile Hub anlegen
  • Zuweisung an Benutzer

Im Followme System steht:


Ich kann ohne weiteres über den MobyDick Client im iPhone Raustelefonieren. Hier wird dann auch die Festnetznummer angezeigt.

Leider aber bekomme ich es nicht hin, dass bei eingehende Anrufen auf der Festnetznummer auch das iPhone mitklingelt.

Wo liegt der Fehler bei meiner Einrichtung oder habe ich etwas übersehen?

Vielen Dank schon mal vorab

Sandro

2

Hallo Sandro,

kannst du mal einen CLI Auszug Posten während eines Anrufs siehe hier.
Und Poste mal deinen Ausgehenden Regeln als Screenshot und die Konfiguration des MobileHub Geräts

Gruß Markus

3

Hallo Markus,

ich habe die Nummern mit XXX… unkenntlich gemacht. Wie ich gesehen interpretiere, wird relativ weit unten versucht mein Handy zu rufen.
Die Rufnummer des Anrufers ist mit 6 X ausgeixt und Meine Rufnummer (welche mit klingeln sollte aber dies nicht tut) ist mit 5 X ausgeixt.

Den Auszug aus der CLI habe ich dir via Nachricht geschickt, da dieser für den Post zu lang gewesen ist. (Post nur 20000 Zeichen)

Nachricht ging auch nicht, hier sind nur 5000 Zeichen möglich.

Ich werde das nun hier aufsplitten in mehrere Teile. Teil 1:


Asterisk certified/11.6-cert12, Copyright (C) 1999 - 2013 Digium, Inc. and others.
Created by Mark Spencer <markster@digium.com>
Asterisk comes with ABSOLUTELY NO WARRANTY; type 'core show warranty' for details.
This is free software, with components licensed under the GNU General Public
License version 2 and other licenses; you are welcome to redistribute it under
certain conditions. Type 'core show license' for details.
=========================================================================
Connected to Asterisk certified/11.6-cert12 currently running on mobydick (pid = 2794)
  == Using SIP RTP TOS bits 184
  == Using SIP RTP CoS mark 5
    -- Executing [620@mdc_incoming-4:1] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_CALLER_NUM_TRUNK=0176XXXXXX44") in new stack
    -- Executing [620@mdc_incoming-4:2] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_CALLEE_NUM_TRUNK=620") in new stack
    -- Executing [620@mdc_incoming-4:3] Goto("SIP/mdc_trunk_conf-4-0000010f", "mdc_trunk-1,s,1") in new stack
    -- Goto (mdc_trunk-1,s,1)
    -- Executing [s@mdc_trunk-1:1] Verbose("SIP/mdc_trunk_conf-4-0000010f", "1,callee number: 620 caller number: 0176XXXXXX44") in new stack
 callee number: 620 caller number: 0176XXXXXX44
    -- Executing [s@mdc_trunk-1:2] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_nat2int,s,1(MDC_CALLER_NUM_INTERNAT,0176XXXXXX44,00,49,0,30,1)") in new stack
    -- Executing [s@sub_nat2int:1] Verbose("SIP/mdc_trunk_conf-4-0000010f", "1,sub_nat2int:: variable: MDC_CALLER_NUM_INTERNAT - number: 0176XXXXXX44 - intVAZ                                        : 00 - lkz: 49 - natVAZ: 0 - onKz: 30 - incoming: 1") in new stack
 sub_nat2int:: variable: MDC_CALLER_NUM_INTERNAT - number: 0176XXXXXX44 - intVAZ: 00 - lkz: 49 - natVAZ: 0 - onKz: 30 - incoming: 1
    -- Executing [s@sub_nat2int:2] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?s-emergency,1") in new stack
    -- Executing [s@sub_nat2int:3] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?s-int,1") in new stack
    -- Executing [s@sub_nat2int:4] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?s-int,1") in new stack
    -- Executing [s@sub_nat2int:5] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?s-convert,1") in new stack
    -- Executing [s@sub_nat2int:6] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?s-int,1") in new stack
    -- Executing [s@sub_nat2int:7] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?s-intshort,1") in new stack
    -- Executing [s@sub_nat2int:8] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?s-natshort,1") in new stack
    -- Executing [s@sub_nat2int:9] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "1?s-nat,1") in new stack
    -- Goto (sub_nat2int,s-nat,1)
    -- Executing [s-nat@sub_nat2int:1] Verbose("SIP/mdc_trunk_conf-4-0000010f", "1,national") in new stack
 national
    -- Executing [s-nat@sub_nat2int:2] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_CALLER_NUM_INTERNAT=0049176XXXXXX44") in new stack
    -- Executing [s-nat@sub_nat2int:3] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [s@mdc_trunk-1:3] Set("SIP/mdc_trunk_conf-4-0000010f", "CALLERID(num)=0049176XXXXXX44") in new stack
    -- Executing [s@mdc_trunk-1:4] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_int2nat,s,1(MDC_CALLER_NUM_NAT,0049176XXXXXX44,00,49,0,30,1)") in new stack
    -- Executing [s@sub_int2nat:1] Verbose("SIP/mdc_trunk_conf-4-0000010f", "1,sub_int2nat:: variable: MDC_CALLER_NUM_NAT - exten: 0049176XXXXXX44 - intVAZ: 0                                        0 - lkz: 49 - natVAZ: 0 - onKz: 30 - incoming: 1") in new stack
 sub_int2nat:: variable: MDC_CALLER_NUM_NAT - exten: 0049176XXXXXX44 - intVAZ: 00 - lkz: 49 - natVAZ: 0 - onKz: 30 - incoming: 1
    -- Executing [s@sub_int2nat:2] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?s-emergency,1") in new stack
    -- Executing [s@sub_int2nat:3] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?nat") in new stack
    -- Executing [s@sub_int2nat:4] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "1?s-internat,1") in new stack
    -- Goto (sub_int2nat,s-internat,1)
    -- Executing [s-internat@sub_int2nat:1] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_CALLER_NUM_NAT=0176XXXXXX44") in new stack
    -- Executing [s-internat@sub_int2nat:2] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [s@mdc_trunk-1:5] Set("SIP/mdc_trunk_conf-4-0000010f", "CALLERID(num)=0176XXXXXX44") in new stack
    -- Executing [s@mdc_trunk-1:6] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_NUMPREFIX_TRUNK=") in new stack
    -- Executing [s@mdc_trunk-1:7] Goto("SIP/mdc_trunk_conf-4-0000010f", "mdc_mapping-1,620,1") in new stack
    -- Goto (mdc_mapping-1,620,1)
    -- Executing [620@mdc_mapping-1:1] Set("SIP/mdc_trunk_conf-4-0000010f", "CHANNEL(language)=de") in new stack
    -- Executing [620@mdc_mapping-1:2] Set("SIP/mdc_trunk_conf-4-0000010f", "CALLERID(name)=celdro media interactive") in new stack
    -- Executing [620@mdc_mapping-1:3] Verbose("SIP/mdc_trunk_conf-4-0000010f", "1,mapping from 620 to 300") in new stack
 mapping from 620 to 300
    -- Executing [620@mdc_mapping-1:4] Goto("SIP/mdc_trunk_conf-4-0000010f", "mdc_external,300,1") in new stack
    -- Goto (mdc_external,300,1)
    -- Executing [300@mdc_external:1] SIPAddHeader("SIP/mdc_trunk_conf-4-0000010f", ""Alert-Info:<http://www.notused.de>;info=alert-external;x-line-id=0"") in                                         new stack
    -- Executing [300@mdc_external:2] GosubIf("SIP/mdc_trunk_conf-4-0000010f", "1?sub_initcall,s,1(ext,300)") in new stack
    -- Executing [s@sub_initcall:1] Verbose("SIP/mdc_trunk_conf-4-0000010f", "1,sub_initcall descent: ext exten: 300") in new stack
 sub_initcall descent: ext exten: 300
    -- Executing [s@sub_initcall:2] GosubIf("SIP/mdc_trunk_conf-4-0000010f", "1?sub_initloop,s,1") in new stack
    -- Executing [s@sub_initloop:1] Verbose("SIP/mdc_trunk_conf-4-0000010f", "1,initial loop") in new stack
 initial loop
    -- Executing [s@sub_initloop:2] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_ALIAS_HOP=0") in new stack
    -- Executing [s@sub_initloop:3] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_MAIN_HOP=0") in new stack
    -- Executing [s@sub_initloop:4] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [s@sub_initcall:3] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_TRANSFERBACK_HOP=0") in new stack
    -- Executing [s@sub_initcall:4] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_DIALDESCENT=ext") in new stack
    -- Executing [s@sub_initcall:5] Goto("SIP/mdc_trunk_conf-4-0000010f", "ext,1") in new stack
    -- Goto (sub_initcall,ext,1)
    -- Executing [ext@sub_initcall:1] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_DIALCALLERNUMINIT=0176XXXXXX44") in new stack
    -- Executing [ext@sub_initcall:2] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_DIALCALLEENUMINIT=620") in new stack
    -- Executing [ext@sub_initcall:3] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_DIALCALLEENUMMAP=300") in new stack
    -- Executing [ext@sub_initcall:4] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [300@mdc_external:3] Goto("SIP/mdc_trunk_conf-4-0000010f", "main,300,1") in new stack
    -- Goto (main,300,1)
    -- Executing [300@main:1] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_MAIN_HOP=1") in new stack
    -- Executing [300@main:2] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?mdc_loop,s,1") in new stack
    -- Executing [300@main:3] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_defcall,s,1(300)") in new stack
    -- Executing [s@sub_defcall:1] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_ALIAS_HOP=1") in new stack
    -- Executing [s@sub_defcall:2] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_DIALCALLEENUM=300") in new stack
    -- Executing [s@sub_defcall:3] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_DIALCALLERNUM=0176XXXXXX44") in new stack
    -- Executing [s@sub_defcall:4] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_DIALCALLERNAME=celdro media interactive") in new stack
    -- Executing [s@sub_defcall:5] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_DIALCHANNELNAME=mdc_trunk_conf-4") in new stack
    -- Executing [s@sub_defcall:6] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [300@main:4] Goto("SIP/mdc_trunk_conf-4-0000010f", "mdc_distribute,300,1") in new stack
    -- Goto (mdc_distribute,300,1)
    -- Executing [300@mdc_distribute:1] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_team,s,1(2,Service,Anruf an Serviceteam,300)") in new stack
    -- Executing [s@sub_team:1] Verbose("SIP/mdc_trunk_conf-4-0000010f", "1,team id: 2 team name: Service team realname: Anruf an Serviceteam own vm: 300") in                                         new stack
 team id: 2 team name: Service team realname: Anruf an Serviceteam own vm: 300
    -- Executing [s@sub_team:2] Set("SIP/mdc_trunk_conf-4-0000010f", "_MDC_CALLEE_TM_ID=2") in new stack
    -- Executing [s@sub_team:3] Set("SIP/mdc_trunk_conf-4-0000010f", "_MDC_CALLEE_TM_NAME=Service") in new stack
    -- Executing [s@sub_team:4] Set("SIP/mdc_trunk_conf-4-0000010f", "_MDC_CALLEE_TM_REALNAME=Anruf an Serviceteam") in new stack
    -- Executing [s@sub_team:5] Set("SIP/mdc_trunk_conf-4-0000010f", "_MDC_CALLEE_VM_OWN=300") in new stack
    -- Executing [s@sub_team:6] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [300@mdc_distribute:2] Goto("SIP/mdc_trunk_conf-4-0000010f", "mdc_team-2,300,1") in new stack
    -- Goto (mdc_team-2,300,1)
    -- Executing [300@mdc_team-2:1] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?mdc_loop,s,1") in new stack
    -- Executing [300@mdc_team-2:2] Set("SIP/mdc_trunk_conf-4-0000010f", "MDC_MAIN_HOP=2") in new stack
    -- Executing [300@mdc_team-2:3] NoOp("SIP/mdc_trunk_conf-4-0000010f", "alias-check:: call forwarding from 300 - 0") in new stack
    -- Executing [300@mdc_team-2:4] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?300-uml,1:300-dial,1") in new stack
    -- Goto (mdc_team-2,300-dial,1)
    -- Executing [300-dial@mdc_team-2:1] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_EXTEN=300") in new stack
    -- Executing [300-dial@mdc_team-2:2] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_prefix-300,ext,1") in new stack
    -- Executing [ext@sub_prefix-300:1] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "1?next_14") in new stack
    -- Goto (sub_prefix-300,ext,3)
    -- Executing [ext@sub_prefix-300:3] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "1?next_15") in new stack
    -- Goto (sub_prefix-300,ext,6)
    -- Executing [ext@sub_prefix-300:6] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "1?next_16") in new stack
    -- Goto (sub_prefix-300,ext,9)
    -- Executing [ext@sub_prefix-300:9] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_timecheck-2,s,1") in new stack
    -- Executing [s@sub_timecheck-2:1] GotoIfTime("SIP/mdc_trunk_conf-4-0000010f", "10:00-18:30,mon-fri,*,*?s-true,1") in new stack
    -- Goto (sub_timecheck-2,s-true,1)
    -- Executing [s-true@sub_timecheck-2:1] Set("SIP/mdc_trunk_conf-4-0000010f", "_MDC_TIMECHECK-2=1") in new stack
    -- Executing [s-true@sub_timecheck-2:2] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [ext@sub_prefix-300:10] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "1?next_17") in new stack
    -- Goto (sub_prefix-300,ext,12)
    -- Executing [ext@sub_prefix-300:12] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_timecheck-2,s,1") in new stack
    -- Executing [s@sub_timecheck-2:1] GotoIfTime("SIP/mdc_trunk_conf-4-0000010f", "10:00-18:30,mon-fri,*,*?s-true,1") in new stack
    -- Goto (sub_timecheck-2,s-true,1)
    -- Executing [s-true@sub_timecheck-2:1] Set("SIP/mdc_trunk_conf-4-0000010f", "_MDC_TIMECHECK-2=1") in new stack
    -- Executing [s-true@sub_timecheck-2:2] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [ext@sub_prefix-300:13] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "1?next_18") in new stack
    -- Goto (sub_prefix-300,ext,16)
    -- Executing [ext@sub_prefix-300:16] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_timecheck-2,s,1") in new stack
    -- Executing [s@sub_timecheck-2:1] GotoIfTime("SIP/mdc_trunk_conf-4-0000010f", "10:00-18:30,mon-fri,*,*?s-true,1") in new stack
    -- Goto (sub_timecheck-2,s-true,1)
    -- Executing [s-true@sub_timecheck-2:1] Set("SIP/mdc_trunk_conf-4-0000010f", "_MDC_TIMECHECK-2=1") in new stack
    -- Executing [s-true@sub_timecheck-2:2] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [ext@sub_prefix-300:17] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "1?next_19") in new stack
    -- Goto (sub_prefix-300,ext,20)
    -- Executing [ext@sub_prefix-300:20] Playback("SIP/mdc_trunk_conf-4-0000010f", "cm-willkommen") in new stack
    -- <SIP/mdc_trunk_conf-4-0000010f> Playing 'cm-willkommen.alaw' (language 'de')
    -- Executing [ext@sub_prefix-300:21] Gosub("SIP/mdc_trunk_conf-4-0000010f", "no_agents_available,s,1") in new stack
    -- Executing [s@no_agents_available:1] NoOp("SIP/mdc_trunk_conf-4-0000010f", "Skripting") in new stack
    -- Executing [s@no_agents_available:2] Set("SIP/mdc_trunk_conf-4-0000010f", "anzahl=2") in new stack
    -- Executing [s@no_agents_available:3] NoOp("SIP/mdc_trunk_conf-4-0000010f", "Anzahl der Mitglieder in der Warteschlange Zentrale: 2") in new stack
    -- Executing [s@no_agents_available:4] GotoIf("SIP/mdc_trunk_conf-4-0000010f", "0?leer") in new stack
    -- Executing [s@no_agents_available:5] Playback("SIP/mdc_trunk_conf-4-0000010f", "cm-bitteGeduld") in new stack
    -- <SIP/mdc_trunk_conf-4-0000010f> Playing 'cm-bitteGeduld.alaw' (language 'de')
    -- Executing [s@no_agents_available:6] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [ext@sub_prefix-300:22] Return("SIP/mdc_trunk_conf-4-0000010f", "") in new stack
    -- Executing [300-dial@mdc_team-2:3] Answer("SIP/mdc_trunk_conf-4-0000010f", "30") in new stack
    -- Executing [300-dial@mdc_team-2:4] Gosub("SIP/mdc_trunk_conf-4-0000010f", "sub_main-300,ext,1") in new stack
    -- Executing [ext@sub_main-300:1] Set("SIP/mdc_trunk_conf-4-0000010f", "__MDC_QUEUE_RINGINUSE=0") in new stack
    -- Executing [ext@sub_main-300:2] Set("SIP/mdc_trunk_conf-4-0000010f", "TMP_DIALOPTION=") in new stack
    -- Executing [ext@sub_main-300:3] Set("SIP/mdc_trunk_conf-4-0000010f", "CALLERID(name)=Anruf an Serviceteam") in new stack
    -- Executing [ext@sub_main-300:4] Set("SIP/mdc_trunk_conf-4-0000010f", "__PICKUPMARK=300") in new stack
    -- Executing [ext@sub_main-300:5] Queue("SIP/mdc_trunk_conf-4-0000010f", "Service,,,,120") in new stack
    -- Started music on hold, class 'Breezy-Summer-Day', on SIP/mdc_trunk_conf-4-0000010f
    -- Called Local/111@mdc_multidial-111
    -- Called Local/113@mdc_multidial-113
    -- Executing [111@mdc_multidial-111:1] Wait("Local/111@mdc_multidial-111-0000023d;2", "0.1") in new stack
    -- Executing [113@mdc_multidial-113:1] Wait("Local/113@mdc_multidial-113-0000023e;2", "0.1") in new stack
    -- Executing [111@mdc_multidial-111:2] Set("Local/111@mdc_multidial-111-0000023d;2", "__MDC_CALLEE_USER_ID=3") in new stack
    -- Executing [111@mdc_multidial-111:3] Set("Local/111@mdc_multidial-111-0000023d;2", "__PICKUPMARK=111") in new stack
    -- Executing [111@mdc_multidial-111:4] ExecIf("Local/111@mdc_multidial-111-0000023d;2", "0?Set(__SPYGROUP=111:):Set(__SPYGROUP=111:0176XXXXXX44)") in new                                         stack
    -- Executing [111@mdc_multidial-111:5] Set("Local/111@mdc_multidial-111-0000023d;2", "__MDC_DIALAGENTNUM=111") in new stack
    -- Executing [111@mdc_multidial-111:6] GotoIf("Local/111@mdc_multidial-111-0000023d;2", "0?111-unavail,1") in new stack
    -- Executing [111@mdc_multidial-111:7] GotoIf("Local/111@mdc_multidial-111-0000023d;2", "0?111-busy,1") in new stack
    -- Executing [111@mdc_multidial-111:8] Dial("Local/111@mdc_multidial-111-0000023d;2", "Local/111@mdc_diallocation") in new stack
    -- Called Local/111@mdc_diallocation
    -- Executing [113@mdc_multidial-113:2] Set("Local/113@mdc_multidial-113-0000023e;2", "__MDC_CALLEE_USER_ID=1") in new stack
    -- Executing [113@mdc_multidial-113:3] Set("Local/113@mdc_multidial-113-0000023e;2", "__PICKUPMARK=113") in new stack
    -- Executing [113@mdc_multidial-113:4] ExecIf("Local/113@mdc_multidial-113-0000023e;2", "0?Set(__SPYGROUP=113:):Set(__SPYGROUP=113:0176XXXXXX44)") in new                                         stack
    -- Executing [113@mdc_multidial-113:5] Set("Local/113@mdc_multidial-113-0000023e;2", "__MDC_DIALAGENTNUM=113") in new stack
    -- Executing [113@mdc_multidial-113:6] GotoIf("Local/113@mdc_multidial-113-0000023e;2", "0?113-unavail,1") in new stack
    -- Executing [113@mdc_multidial-113:7] GotoIf("Local/113@mdc_multidial-113-0000023e;2", "0?113-busy,1") in new stack
    -- Executing [113@mdc_multidial-113:8] Dial("Local/113@mdc_multidial-113-0000023e;2", "Local/113@mdc_diallocation") in new stack
    -- Called Local/113@mdc_diallocation
    -- Executing [111@mdc_diallocation:1] Verbose("Local/111@mdc_diallocation-0000023f;2", "1,dial to 111 for user 3") in new stack

Vielen lieben Dank für die Unterstützung.

Bis dann

Sandro

4

Teil 2 des CLI Auszugs:


dial to 111 for user 3
    -- Executing [111@mdc_diallocation:2] Set("Local/111@mdc_diallocation-0000023f;2", "__MDC_DIALLOCATION_CHANNEL=Local/111@mdc_diallocation-0000023f;2") in                                         new stack
    -- Executing [111@mdc_diallocation:3] Set("Local/111@mdc_diallocation-0000023f;2", "SHARED(MDC_CALLEE_PEERS)=") in new stack
    -- Executing [111@mdc_diallocation:4] Set("Local/111@mdc_diallocation-0000023f;2", "MDC_EXTEN=111") in new stack
    -- Executing [111@mdc_diallocation:5] Wait("Local/111@mdc_diallocation-0000023f;2", "0.25") in new stack
    -- Executing [113@mdc_diallocation:1] Verbose("Local/113@mdc_diallocation-00000240;2", "1,dial to 113 for user 1") in new stack
 dial to 113 for user 1
    -- Executing [113@mdc_diallocation:2] Set("Local/113@mdc_diallocation-00000240;2", "__MDC_DIALLOCATION_CHANNEL=Local/113@mdc_diallocation-00000240;2") in                                         new stack
    -- Executing [113@mdc_diallocation:3] Set("Local/113@mdc_diallocation-00000240;2", "SHARED(MDC_CALLEE_PEERS)=") in new stack
    -- Executing [113@mdc_diallocation:4] Set("Local/113@mdc_diallocation-00000240;2", "MDC_EXTEN=113") in new stack
    -- Executing [113@mdc_diallocation:5] Wait("Local/113@mdc_diallocation-00000240;2", "0.25") in new stack
    -- Executing [111@mdc_diallocation:6] ExecIf("Local/111@mdc_diallocation-0000023f;2", "1?Set(TMP_TARGET=team):Set(TMP_TARGET=ext)") in new stack
    -- Executing [111@mdc_diallocation:7] Gosub("Local/111@mdc_diallocation-0000023f;2", "sub_split-user,s,1(3)") in new stack
    -- Executing [s@sub_split-user:1] Verbose("Local/111@mdc_diallocation-0000023f;2", "1,get locations for for: 3") in new stack
 get locations for for: 3
    -- Executing [s@sub_split-user:2] GotoIf("Local/111@mdc_diallocation-0000023f;2", "0?s-zero,1") in new stack
    -- Executing [s@sub_split-user:3] Set("Local/111@mdc_diallocation-0000023f;2", "TMP_LOCATIONS=3;0") in new stack
    -- Executing [s@sub_split-user:4] Set("Local/111@mdc_diallocation-0000023f;2", "TMP_STATIC_ID=3") in new stack
    -- Executing [s@sub_split-user:5] Verbose("Local/111@mdc_diallocation-0000023f;2", "1,static id: 3") in new stack
 static id: 3
    -- Executing [s@sub_split-user:6] Set("Local/111@mdc_diallocation-0000023f;2", "TMP_DYN_ID=0") in new stack
    -- Executing [s@sub_split-user:7] Verbose("Local/111@mdc_diallocation-0000023f;2", "1,dynamic id: 0") in new stack
 dynamic id: 0
    -- Executing [s@sub_split-user:8] Return("Local/111@mdc_diallocation-0000023f;2", "") in new stack
    -- Executing [111@mdc_diallocation:8] GotoIf("Local/111@mdc_diallocation-0000023f;2", "0?invalid,1") in new stack
    -- Executing [111@mdc_diallocation:9] GotoIf("Local/111@mdc_diallocation-0000023f;2", "0?dynamic,1") in new stack
    -- Executing [111@mdc_diallocation:10] GotoIf("Local/111@mdc_diallocation-0000023f;2", "1?static,1") in new stack
    -- Goto (mdc_diallocation,static,1)
    -- Executing [static@mdc_diallocation:1] Dial("Local/111@mdc_diallocation-0000023f;2", "Local/team@mdc_locallocation-3") in new stack
    -- Called Local/team@mdc_locallocation-3
    -- Executing [113@mdc_diallocation:6] ExecIf("Local/113@mdc_diallocation-00000240;2", "1?Set(TMP_TARGET=team):Set(TMP_TARGET=ext)") in new stack
    -- Executing [113@mdc_diallocation:7] Gosub("Local/113@mdc_diallocation-00000240;2", "sub_split-user,s,1(1)") in new stack
    -- Executing [s@sub_split-user:1] Verbose("Local/113@mdc_diallocation-00000240;2", "1,get locations for for: 1") in new stack
 get locations for for: 1
    -- Executing [s@sub_split-user:2] GotoIf("Local/113@mdc_diallocation-00000240;2", "0?s-zero,1") in new stack
    -- Executing [s@sub_split-user:3] Set("Local/113@mdc_diallocation-00000240;2", "TMP_LOCATIONS=1;0") in new stack
    -- Executing [s@sub_split-user:4] Set("Local/113@mdc_diallocation-00000240;2", "TMP_STATIC_ID=1") in new stack
    -- Executing [s@sub_split-user:5] Verbose("Local/113@mdc_diallocation-00000240;2", "1,static id: 1") in new stack
 static id: 1
    -- Executing [s@sub_split-user:6] Set("Local/113@mdc_diallocation-00000240;2", "TMP_DYN_ID=0") in new stack
    -- Executing [s@sub_split-user:7] Verbose("Local/113@mdc_diallocation-00000240;2", "1,dynamic id: 0") in new stack
 dynamic id: 0
    -- Executing [s@sub_split-user:8] Return("Local/113@mdc_diallocation-00000240;2", "") in new stack
    -- Executing [113@mdc_diallocation:8] GotoIf("Local/113@mdc_diallocation-00000240;2", "0?invalid,1") in new stack
    -- Executing [113@mdc_diallocation:9] GotoIf("Local/113@mdc_diallocation-00000240;2", "0?dynamic,1") in new stack
    -- Executing [113@mdc_diallocation:10] GotoIf("Local/113@mdc_diallocation-00000240;2", "1?static,1") in new stack
    -- Goto (mdc_diallocation,static,1)
    -- Executing [static@mdc_diallocation:1] Dial("Local/113@mdc_diallocation-00000240;2", "Local/team@mdc_locallocation-1") in new stack
    -- Called Local/team@mdc_locallocation-1
    -- Executing [team@mdc_locallocation-3:1] Set("Local/team@mdc_locallocation-3-00000241;2", "PUSH(SHARED(MDC_CALLEE_PEERS,Local/111@mdc_diallocation-000002                                        3f;2))=Local/team-2@mdc_localdevice-3") in new stack
    -- Executing [team@mdc_locallocation-3:2] Set("Local/team@mdc_locallocation-3-00000241;2", "PUSH(SHARED(MDC_CALLEE_PEERS,Local/111@mdc_diallocation-000002                                        3f;2))=Local/team-14@mdc_localdevice-3") in new stack
    -- Executing [team@mdc_locallocation-3:3] Dial("Local/team@mdc_locallocation-3-00000241;2", "Local/team-2@mdc_localdevice-3&Local/team-14@mdc_localdevice-                                        3") in new stack
    -- Called Local/team-2@mdc_localdevice-3
    -- Called Local/team-14@mdc_localdevice-3
    -- Executing [team@mdc_locallocation-1:1] Set("Local/team@mdc_locallocation-1-00000242;2", "PUSH(SHARED(MDC_CALLEE_PEERS,Local/113@mdc_diallocation-000002                                        40;2))=Local/team-15@mdc_localdevice-1") in new stack
    -- Executing [team@mdc_locallocation-1:2] Set("Local/team@mdc_locallocation-1-00000242;2", "PUSH(SHARED(MDC_CALLEE_PEERS,Local/113@mdc_diallocation-000002                                        40;2))=Local/team-1@mdc_localdevice-1") in new stack
    -- Executing [team@mdc_locallocation-1:3] Set("Local/team@mdc_locallocation-1-00000242;2", "PUSH(SHARED(MDC_CALLEE_PEERS,Local/113@mdc_diallocation-000002                                        40;2))=Local/team-13@mdc_localdevice-1") in new stack
    -- Executing [team@mdc_locallocation-1:4] Dial("Local/team@mdc_locallocation-1-00000242;2", "Local/team-15@mdc_localdevice-1&Local/team-1@mdc_localdevice-                                        1&Local/team-13@mdc_localdevice-1") in new stack
    -- Called Local/team-15@mdc_localdevice-1
    -- Called Local/team-1@mdc_localdevice-1
    -- Called Local/team-13@mdc_localdevice-1
    -- Executing [team-2@mdc_localdevice-3:1] Verbose("Local/team-2@mdc_localdevice-3-00000243;2", "1,Dialing with delay of 0 seconds for 999 seconds") in new                                         stack
 Dialing with delay of 0 seconds for 999 seconds
    -- Executing [team-2@mdc_localdevice-3:2] Dial("Local/team-2@mdc_localdevice-3-00000243;2", "SIP/GihgA51yhEQdrfa,999,i") in new stack
[May 13 13:49:14] WARNING[8087][C-00000091]: app_dial.c:2437 dial_exec_full: Unable to create channel of type 'SIP' (cause 20 - Subscriber absent)
  == Everyone is busy/congested at this time (1:0/0/1)
    -- Executing [team-2@mdc_localdevice-3:3] Verbose("Local/team-2@mdc_localdevice-3-00000243;2", "1,mdc_localdevice-Dialstatus: CHANUNAVAIL - cause: 20") in                                         new stack
 mdc_localdevice-Dialstatus: CHANUNAVAIL - cause: 20
    -- Executing [team-2@mdc_localdevice-3:4] Gosub("Local/team-2@mdc_localdevice-3-00000243;2", "sub_hangup,s,1(CHANUNAVAIL)") in new stack
    -- Executing [s@sub_hangup:1] Verbose("Local/team-2@mdc_localdevice-3-00000243;2", "1,sub_hangup dialstatus: CHANUNAVAIL") in new stack
 sub_hangup dialstatus: CHANUNAVAIL
    -- Executing [s@sub_hangup:2] GotoIf("Local/team-2@mdc_localdevice-3-00000243;2", "0?noanswer,1") in new stack
    -- Executing [s@sub_hangup:3] GotoIf("Local/team-2@mdc_localdevice-3-00000243;2", "0?busy,1") in new stack
    -- Executing [s@sub_hangup:4] GotoIf("Local/team-2@mdc_localdevice-3-00000243;2", "0?busy,1") in new stack
    -- Executing [s@sub_hangup:5] Goto("Local/team-2@mdc_localdevice-3-00000243;2", "unavailable,1") in new stack
    -- Goto (sub_hangup,unavailable,1)
    -- Executing [unavailable@sub_hangup:1] Hangup("Local/team-2@mdc_localdevice-3-00000243;2", "20") in new stack
  == Spawn extension (sub_hangup, unavailable, 1) exited non-zero on 'Local/team-2@mdc_localdevice-3-00000243;2'
    -- Executing [team-14@mdc_localdevice-3:1] Verbose("Local/team-14@mdc_localdevice-3-00000244;2", "1,Dialing with delay of 0 seconds for 999 seconds") in n                                        ew stack
 Dialing with delay of 0 seconds for 999 seconds
    -- Executing [team-14@mdc_localdevice-3:2] Dial("Local/team-14@mdc_localdevice-3-00000244;2", "SIP/0OHLoLeR34b451e,999,i") in new stack
  == Using SIP RTP TOS bits 184
  == Using SIP RTP CoS mark 5
    -- Called SIP/0OHLoLeR34b451e
    -- Executing [team-15@mdc_localdevice-1:1] Verbose("Local/team-15@mdc_localdevice-1-00000245;2", "1,Dialing with delay of 0 seconds for 999 seconds") in n                                        ew stack
 Dialing with delay of 0 seconds for 999 seconds
    -- Executing [team-15@mdc_localdevice-1:2] Dial("Local/team-15@mdc_localdevice-1-00000245;2", "Local/s@mdc_extphone-3/n,999,i") in new stack
    -- Called Local/s@mdc_extphone-3/n
    -- Executing [team-1@mdc_localdevice-1:1] Verbose("Local/team-1@mdc_localdevice-1-00000246;2", "1,Dialing with delay of 0 seconds for 999 seconds") in new                                         stack
 Dialing with delay of 0 seconds for 999 seconds
    -- Executing [team-1@mdc_localdevice-1:2] Dial("Local/team-1@mdc_localdevice-1-00000246;2", "SIP/Ea1VfsizJwSa9Ju,999,i") in new stack
[May 13 13:49:14] WARNING[8090][C-00000091]: app_dial.c:2437 dial_exec_full: Unable to create channel of type 'SIP' (cause 20 - Subscriber absent)
  == Everyone is busy/congested at this time (1:0/0/1)
    -- Executing [team-1@mdc_localdevice-1:3] Verbose("Local/team-1@mdc_localdevice-1-00000246;2", "1,mdc_localdevice-Dialstatus: CHANUNAVAIL - cause: 20") in                                         new stack
 mdc_localdevice-Dialstatus: CHANUNAVAIL - cause: 20
    -- Executing [team-1@mdc_localdevice-1:4] Gosub("Local/team-1@mdc_localdevice-1-00000246;2", "sub_hangup,s,1(CHANUNAVAIL)") in new stack
    -- Executing [s@sub_hangup:1] Verbose("Local/team-1@mdc_localdevice-1-00000246;2", "1,sub_hangup dialstatus: CHANUNAVAIL") in new stack
 sub_hangup dialstatus: CHANUNAVAIL
    -- Executing [s@sub_hangup:2] GotoIf("Local/team-1@mdc_localdevice-1-00000246;2", "0?noanswer,1") in new stack
    -- Executing [s@sub_hangup:3] GotoIf("Local/team-1@mdc_localdevice-1-00000246;2", "0?busy,1") in new stack
    -- Executing [s@sub_hangup:4] GotoIf("Local/team-1@mdc_localdevice-1-00000246;2", "0?busy,1") in new stack
    -- Executing [s@sub_hangup:5] Goto("Local/team-1@mdc_localdevice-1-00000246;2", "unavailable,1") in new stack
    -- Goto (sub_hangup,unavailable,1)
    -- Executing [unavailable@sub_hangup:1] Hangup("Local/team-1@mdc_localdevice-1-00000246;2", "20") in new stack
  == Spawn extension (sub_hangup, unavailable, 1) exited non-zero on 'Local/team-1@mdc_localdevice-1-00000246;2'
    -- Executing [team-13@mdc_localdevice-1:1] Verbose("Local/team-13@mdc_localdevice-1-00000247;2", "1,Dialing with delay of 0 seconds for 999 seconds") in n                                        ew stack
 Dialing with delay of 0 seconds for 999 seconds
    -- Executing [team-13@mdc_localdevice-1:2] Dial("Local/team-13@mdc_localdevice-1-00000247;2", "SIP/8Z5CUiwW44b4669,999,i") in new stack
  == Using SIP RTP TOS bits 184
  == Using SIP RTP CoS mark 5
    -- Called SIP/8Z5CUiwW44b4669
    -- Executing [s@mdc_extphone-3:1] Set("Local/s@mdc_extphone-3-00000248;2", "_MDC_DIALEXTPHONE=3") in new stack
    -- Executing [s@mdc_extphone-3:2] Dial("Local/s@mdc_extphone-3-00000248;2", "Local/0049176XXXXX614@mdc_outgoing") in new stack
[May 13 13:49:14] NOTICE[8092][C-00000091]: chan_local.c:968 local_call: No such extension/context 0049176XXXXX614@mdc_outgoing while calling Local channel
    -- Couldn't call Local/0049176XXXXX614@mdc_outgoing
  == Everyone is busy/congested at this time (0:0/0/0)
    -- Executing [s@mdc_extphone-3:3] NoOp("Local/s@mdc_extphone-3-00000248;2", "Dialstatus: CHANUNAVAIL") in new stack
    -- Auto fallthrough, channel 'Local/s@mdc_extphone-3-00000248;2' status is 'CHANUNAVAIL'
    -- Local/s@mdc_extphone-3-00000248;1 is circuit-busy
  == Everyone is busy/congested at this time (1:0/1/0)
    -- Executing [team-15@mdc_localdevice-1:3] Verbose("Local/team-15@mdc_localdevice-1-00000245;2", "1,mdc_localdevice-Dialstatus: CONGESTION - cause: 0") in                                         new stack
 mdc_localdevice-Dialstatus: CONGESTION - cause: 0
    -- Executing [team-15@mdc_localdevice-1:4] Gosub("Local/team-15@mdc_localdevice-1-00000245;2", "sub_hangup,s,1(CONGESTION)") in new stack
    -- Executing [s@sub_hangup:1] Verbose("Local/team-15@mdc_localdevice-1-00000245;2", "1,sub_hangup dialstatus: CONGESTION") in new stack
 sub_hangup dialstatus: CONGESTION
    -- Executing [s@sub_hangup:2] GotoIf("Local/team-15@mdc_localdevice-1-00000245;2", "0?noanswer,1") in new stack
    -- Executing [s@sub_hangup:3] GotoIf("Local/team-15@mdc_localdevice-1-00000245;2", "0?busy,1") in new stack
    -- Executing [s@sub_hangup:4] GotoIf("Local/team-15@mdc_localdevice-1-00000245;2", "1?busy,1") in new stack
    -- Goto (sub_hangup,busy,1)
    -- Executing [busy@sub_hangup:1] Hangup("Local/team-15@mdc_localdevice-1-00000245;2", "17") in new stack
  == Spawn extension (sub_hangup, busy, 1) exited non-zero on 'Local/team-15@mdc_localdevice-1-00000245;2'
    -- Executing [h@mdc_extphone-3:1] Gosub("Local/s@mdc_extphone-3-00000248;2", "def_hangup,s,1(,CHANUNAVAIL,,CALL)") in new stack
    -- Executing [s@def_hangup:1] NoOp("Local/s@mdc_extphone-3-00000248;2", ">>>def_hangup:: EXTEN:  DIALSTATUS: CHANUNAVAIL QUEUESTATUS:  REASON: CALL") in n                                        ew stack
  == Extension Changed 111[mdc_hint-ident] new state Ringing for Notify User 8Z5CUiwW44b4669
  == Extension Changed 113[mdc_hint-ident] new state Ringing for Notify User 0OHLoLeR34b451e
    -- SIP/0OHLoLeR34b451e-00000110 is ringing
    -- Local/team-14@mdc_localdevice-3-00000244;1 is ringing
    -- Local/team@mdc_locallocation-3-00000241;1 is ringing
    -- Local/111@mdc_diallocation-0000023f;1 is ringing
    -- Local/111@mdc_multidial-111-0000023d;1 is ringing
    -- SIP/8Z5CUiwW44b4669-00000111 is ringing
    -- Local/team-13@mdc_localdevice-1-00000247;1 is ringing
    -- Local/team@mdc_locallocation-1-00000242;1 is ringing
    -- Local/113@mdc_diallocation-00000240;1 is ringing
    -- Local/113@mdc_multidial-113-0000023e;1 is ringing
    -- SIP/0OHLoLeR34b451e-00000110 is ringing
    -- SIP/8Z5CUiwW44b4669-00000111 is ringing
    -- SIP/0OHLoLeR34b451e-00000110 is ringing
    -- SIP/8Z5CUiwW44b4669-00000111 is ringing
    -- SIP/0OHLoLeR34b451e-00000110 is ringing
    -- SIP/8Z5CUiwW44b4669-00000111 is ringing
    -- SIP/0OHLoLeR34b451e-00000110 is ringing
    -- SIP/8Z5CUiwW44b4669-00000111 is ringing
    -- Stopped music on hold on SIP/mdc_trunk_conf-4-0000010f
  == Spawn extension (sub_main-300, ext, 5) exited non-zero on 'SIP/mdc_trunk_conf-4-0000010f'
    -- Executing [h@sub_main-300:1] Gosub("SIP/mdc_trunk_conf-4-0000010f", "def_hangup,s,1(300,,,CALL)") in new stack
    -- Executing [s@def_hangup:1] NoOp("SIP/mdc_trunk_conf-4-0000010f", ">>>def_hangup:: EXTEN: 300 DIALSTATUS:  QUEUESTATUS:  REASON: CALL") in new stack
  == Spawn extension (mdc_multidial-111, 111, 8) exited non-zero on 'Local/111@mdc_multidial-111-0000023d;2'
  == Spawn extension (mdc_multidial-113, 113, 8) exited non-zero on 'Local/113@mdc_multidial-113-0000023e;2'
  == Spawn extension (mdc_diallocation, static, 1) exited non-zero on 'Local/111@mdc_diallocation-0000023f;2'
  == Spawn extension (mdc_diallocation, static, 1) exited non-zero on 'Local/113@mdc_diallocation-00000240;2'
  == Spawn extension (mdc_locallocation-3, team, 3) exited non-zero on 'Local/team@mdc_locallocation-3-00000241;2'
  == Spawn extension (mdc_locallocation-1, team, 4) exited non-zero on 'Local/team@mdc_locallocation-1-00000242;2'
  == Spawn extension (mdc_localdevice-3, team-14, 2) exited non-zero on 'Local/team-14@mdc_localdevice-3-00000244;2'
  == Spawn extension (mdc_localdevice-1, team-13, 2) exited non-zero on 'Local/team-13@mdc_localdevice-1-00000247;2'
  == Extension Changed 111[mdc_hint-ident] new state Idle for Notify User 8Z5CUiwW44b4669
  == Extension Changed 113[mdc_hint-ident] new state Idle for Notify User 0OHLoLeR34b451e
mobydick*CLI>

Sollten hier noch Informationen enthalten sein, welche besser nicht öffentlich sind, würde ich mich über einen kurzen Hinweis freuen, da ich die betreffenden Stellen
ausixen könnte.

Vielen Dank für die Hilfe

Noch eine kurze Frage: Genügt die Anweisung quit um die CLI zu schließen oder muss man dieser noch durch einen anderen Befehl beenden?

Sandro

5

Hallo Markus,

ich hatte vergessen die Ausgehenden Regeln und die Konfiguration des MobileHub als Screenshot anzufertigen. Hiermit wird das nachgeholt:


ba5c29e0af56deaa57bb7958b802fef05da97af8.jpg900×77 29.8 KB

Bis dann

Sandro
